In the studio or on stage the P-84's warm, natural and detailed character provides an authentic un-hyped reproduction of a wide variety of sources. The first phantom powered microphone, the KM 84 remains the standard by which all modern SDC FET pencil microphones are judged. Like the KM 84, the P-84 achieves a balanced output through a generously sized transformer, eliminating interference and distortion. The P-84 is true to its inspiration in capsule and circuit design. With the higher quality available in today's electrical components, we have been able to improve low frequency responsiveness and raise the sound pressure level capacity. The P-84 brings authentic natural warmth and detail to satisfy the demands of the modern digital recording environment.
Microphone kit comes as a complete system including: Two P-84 Microphones in Wood Boxes, Two Omni and Two Cardioid Capsules with the Extra Capsules in a Wood Box, Two Shock Mounts, Two Hard Mounts, and a Stereo Mounting Bar, all packed in a Flight Case.
Technical Data
Capsule Type: Condenser Pressure Gradient w/ 20mm capsule
Frequency Range: 20Hz/20Khz
Polar Pattern: Omni and Cardioid
Sensitivity: 15 mv/pa
Impedance: 200 ohms
SPL: 142 dB
Equivalent Noise: 14 dB(A)
Power Requirements: Phantom - 48v +/- 4v
Current Consumption: < 3.0 MA
Size: 22mm x 124 mm
Weight: 130 g
