SCM0.1/15-PRO - 15" Active Sub Bass
The SCM0.1/15 Pro has a rugged 375mm bass driver, driven by a built in 1000 W amplifier to deliver over 115dB@1m at very low levels of distortion, right down to 20Hz. The SCM0.1/15 Pro can be used to monitor the LFE channel in surround applications or to extend the low frequency in channel systems with smaller main monitors such as the SCM20ASL Pro. A versatile user interface provides control of gain, cut-off frequency, frequency contour and phase.
Features
- Full "SL" spec 15"/375mm bass driver
- Massive motor assembly.
- In-house, hand wound precision flat wire coils.
- 1000W Class G amplifier
- Active filters and overload protection
- Phase adjustment
- Variable cut off frequency
- Variable gain
- Stereo inputs
- 6 year warranty
Technical Specifications
- Driver: LF 375mm /15"
- Amplitude Linearity (+/-2dB): 30Hz-300Hz
- Cut-off Frequency (-3dB, free standing): 20 Hz
- Max. Continuous SPL (1 metre): 115dB
- Input Connectors: 2x XLR-m
- Input Sensitivity: 1V
- Input Impedance: Balanced > 10kOhms
- Amplifier Output: 650W (RMS) / 1000W
- THD, Ampligier: < 0.01%
- Gain: +/- 6dB
- Contour Equalizer: 6dB lift @ 40-60Hz
- Filters: 50, 60, 70, 80,90 Hz low pass second order critically Damped
- Overload Protection: Active FET momentary gain reduction
- Panel Indicators: Power On indicator
- Dimensions (HxWxD): 624 x 580 x 580 mm
- Weight: 60kg
