The Chandler Little Devil Equalizer uses all discrete circuits that combine Chandler's best designs with the hottest designs from the past, transformer balanced everything, and the American hand made quality you expect from Chandler, the LITTLE DEVILS will take the lunchbox UP to the next level...
Technically and sonically speaking, the Chandler LITTLE DEVILS are steeped in the sound and function of all Chandler gear - discrete amplifiers, inductors, transformers, and quality American build. You won't find any surface mount or ribbon cables in the Little Devils (used to build cell phones and computers) that are becoming popular money-saving and sound-crippling build techniques used by some other manufacturers.
Features
- 500 series modular equalizer
- 4-band english-style console EQ (1071/33115 vintage units)
- Hi/Low-Shelving EQ
- Hi Mid/Lo Mid parametric EQ
- Three position Low Cut Filter
- Transformer balanced in- and output
Technical Specifications
- Connectors: Multiport Connector (500 series)
- THD: 0.0065%
- Input Impedance: 10k ohms
- Output Impedance: 600 ohms
- Output Level (max): 28.8dB
- Bass Band: +/- 18dB, 50, 110 Hz
- Lo-Mid Band: +/- 18dB, 820, 560, 470, 390, 330, 270, 220 Hz, 2x Q-settings
- Hi-Mid Band: +/- 18dB, 8k2, 6k8, 5k6, 4k7, 3k3, 2k7, 1k2 Hz, 2x Q-settings
- Treble Band: +/- 18dB, 12kHz
- Dimmensions (w x h x d): 38 x 133 x 153 mm (1 spaces '500' rack)
- Power Requirements: 500 series internal psu
